Schneider Products for Motor protection and control ATS48C41Q
| Range of product | Altistart 48 |
| Product or component type | Soft starter |
| Product destination | Asynchronous motors |
| Product specific application | Heavy duty industry and pumps |
| Device short name | ATS48 |
| Power supply voltage | 230…415 V (- 15…10 %) |
| Motor power kW | 90 kW at 230 V (connection in the motor supply line) for severe applications
110 kW at 230 V (connection in the motor supply line) for standard applications 160 kW at 230 V (connection to the motor delta terminals) for severe applications 160 kW at 400 V (connection in the motor supply line) for severe applications 220 kW at 230 V (connection to the motor delta terminals) for standard applications 220 kW at 400 V (connection in the motor supply line) for standard applications 250 kW at 400 V (connection to the motor delta terminals) for severe applications 315 kW at 400 V (connection to the motor delta terminals) for standard applications |
| Power dissipation in W | For severe applications 1017 W
For standard applications 1339 W |
| Utilisation category | AC-53A |
| Type of start | Start with torque control (current limited to 5 In) |
| Icl nominal current | 410 A (connection in the motor supply line) for severe applications
710 A (connection to the motor delta terminals) for severe applications 710 A (connection to the motor delta terminals) for standard applications 410 A (connection in the motor supply line) for standard applications |
| IP degree of protection | IP00 |
| Assembly style | With heat sink |
| Function available | External bypass (optional) |
| Power supply voltage limits | 195…456 V |
| Power supply frequency | 50…60 Hz (- 5…5 %) |
| Power supply frequency limits | 47.5…63 Hz |
| Device connection | In the motor supply line
To the motor delta terminals |
| Factory setting current | 388 A |
| [Uc] control circuit voltage | 220 – 15 % to 415 + 10 %, 50/60 Hz |
| Control circuit consumption | 80 W |
| Marking | CE |
| Type of cooling | Forced convection |
| Operating position | Vertical +/- 10 degree |
| Height | 670 mm |
| Width | 400 mm |
| Depth | 300 mm |
| Product weight | 51.4 kg |
Schneider Products for Motor protection and control ATS48C41Q
We are specialized in intelligent instruments, including : control system, transmitters, flow meters,sensors, recorders, analyzers, control valves, controllers, PLC’s, etc.
We mainly supply YOKOGAWA, Siemens, Honeywell , Rosemount, Endress Hauser, ABB, Weidmuller, ABB, MOELLER, Schneider Electic , Omron , Fluke , PEPPERL+FUCHS,etc.
Schneider Products for Motor protection and control ATS48C41Q
1.100% original product, 100% quality assurance.
If you find a fake. Please contact us without hesitation! We afford the shipment cost! We send you a new product asking zero cent!
2.Varied payment methods.
We adopt T/T, western union and paypal. If you can not trust us , you can choose to pay it via Aliexpress! 100% make your money safe!
3.SHIPPING:
We can shipping all over the world.via DHL,UPS,Fedex,TNT and EMS etc., the packaging is very safe and strong. if you have any special needs,please notify me.
It will take 3 to 7days to reach in your hands.
Schneider Products for Motor protection and control ATS48C41Q
Imported with original packaging or standard export packing.Customize design is acceptable.
