Phoenix Power supply unit – QUINT-PS/1AC/24DC/20 – 2866776

  • QUINT-PS/1AC/24DC/20 - 2866776

    Specifications


    Primary-switched power supply unit, QUINT POWER, Screw connection, DIN rail mounting, SFB Technology (Selective Fuse Breaking), input: 1-phase, output: 24 V DC / 20 A

    Product Description

    QUINT POWER power supplies with maximum functionality
    QUINT POWER circuit breakers magnetically and therefore quickly trip at six times the nominal current, for selective and therefore cost-effective system protection. The high level of system availability is additionally ensured, thanks to preventive function monitoring, as it reports critical operating states before errors occur.
    Reliable starting of heavy loads takes place via the static power reserve POWER BOOST. Thanks to the adjustable voltage, all ranges between 5 V DC … 56 V DC are covered.

    Your advantages

    • For superior system availability
    • Reliable starting of difficult loads with the static POWER BOOST power reserve with up to 1.5 times the nominal current permanently
    • Fast tripping of standard circuit breakers with dynamic power reserve SFB (selective fuse breaking) technology with up to 6 times the nominal current for 12 ms
    • Preventive function monitoring

    Key Commercial Data

    Orderkey2866776
    Packing unit1 pc
    Catalog pagePage 159 (C-6-2015)
    GTIN4046356113557
    Weight per Piece (excluding packing)2,100.500 g
    Custom tariff number85044030
    Country of originTH (Thailand)
