Rosemount Emerson AMS Trex Device Communicator TREXLFPKLWS3S

  • Weight Approximately 2.9 lbs (1330 grams) Microprocessor 800 MHZ ARM Cortex A8/NXP Memory Internal Flash 2 GB NAND and 32 GB extended flash RAM 512 MB DDR3 SDRAM Display 5.7 in (14.5 cm) color VGA resistive touchscreen Battery Operating Time 8+ hours of typical use Operating Temperature -20 to 55°C (-4 to 122°F) Enclosure Rating IP54 Shock Tested to survive a 1-meter drop test onto concrete

    Specifications


    Emerson AMS Trex Device Communicator TREXLFPKLWS3S

    Emerson AMS trex device communicatorFeatures

    • Enables HART or Fieldbus module communications
    • 7in (14.5 cm) color VGA resistive touchscreen display
    • Configure and test valves inline
    • 2 GB NAND and 32 GB extended flash
    • Rechargeable lithium-ion power module
    • 800 MHz ARM Cortex A8 / NXP
    • -4 to 131°F (-20 to 55°C) operating temp
    • IP54 environmental rating



    The Emerson AMS Trex device communicator is designed for comfortable, one-handed, all-day operation in the field. It is packaged in an evenly-balanced form factor with a rugged hand strap so it is easy to hold, even when working in tight spaces. It comes standard with 32 GB of application memory, providing plenty of space to customize with the apps of your choice. With built-in Bluetooth, USB, and WiFi connectivity, data can be moved to and from the communicator using whichever connectivity option is most convenient.



    Emerson AMS Trex Device Communicator TREXLFPKLWS3S

    Emerson AMS Trex Device

    The Trex communicator features a 5.7 inch resistive touchscreen display that is easy to use with bulky work gloves. The adjustable backlit screen can be adjusted to save power and adapt to dark environments or bright sunlight, ensuring a crisp display that is always easy to read.

    Improve reliability with the AMS Trex Device Communicator TREXLFPKLWS3S. Increase productivity in the field with your Trex unit by doing more types of tasks. Easily solve complex device issues without the need for other specialized tools. The Trex communicator is designed to withstand the harsh conditions in and around manufacturing facilities and is safely-rated, so it can go anywhere you can go. Rely on Trex to deliver results and keep your field assets reliable.

    Ordering Codes:

    AMS Trex Device Communicator TREXLFPKLWS3S
    Model Product Description
    TREX Base Trex Platform (1)
    Code Communication Module
    C Device Communicator communication module
    L Device Communicator Plus communication module(2)
    Code Applications
    H HART Application
    F HART + Foundation Fieldbus Applications(3)
    Code Power Module Type
    P Rechargeable Li-Ion Power Module
    Code Product Certifications
    KL ATEX, CSA (US/Canada) and IECEx Intrinsically Safe (includes FISCO as applicable)
    NA No Approval
    Code Radio Options
    W Wireless
    9 None
    Code Support
    S1 Standard Support (1 Year)(6)
    S3 Standard Support (3 Year)(6)
    P1 Premium Support (1 Year)(
    P3 Premium Support (3 Year)(
    Code Carrying Case
    S Carrying Case



    TREXLFPKLWS3S TREXLHPNAWS1S TREXCFPNAWS1S TREXLFPNAWS1S
    TREXCHPNAWS3S TREXLHPNAWS3S TREXCFPNAWS3S TREXLFPNAWS3S
    TREXCHPNAWP1S TREXLHPNAWP1S TREXCFPNAWP1S TREXLFPNAWP1S
    TREXCHPNAWP3S TREXLHPNAWP3S TREXCFPNAWP3S TREXLFPNAWP3S
    TREXCHPNA9S1S TREXLHPNA9S1S TREXCFPNA9S1S TREXLFPNA9S1S
    TREXCHPNA9S3S TREXLHPNA9S3S TREXCFPNA9S3S TREXLFPNA9S3S
    TREXCHPNA9P1S TREXLHPNA9P1S TREXCFPNA9P1S TREXLFPNA9P1S
    TREXCHPNA9P3S TREXLHPNA9P3S TREXCFPNA9P3S TREXLFPNA9P3S
    TREXCHPKLWS1S TREXLHPKLWS1S TREXCFPKLWS1S TREXLFPKLWS1S
    TREXCHPKLWS3S TREXLHPKLWS3S TREXCFPKLWS3S TREXLFPKLWS3
    TREXCHPKLWP1S TREXLHPKLWP1S TREXCFPKLWP1S TREXLFPKLWP1S
    TREXCHPKLWP3S TREXLHPKLWP3S TREXCFPKLWP3S TREXLFPKLWP3S
    TREXCHPKL9S1S TREXLHPKL9S1S TREXCFPKL9S1S TREXLFPKL9S1S
    TREXCHPKL9S3S TREXLHPKL9S3S TREXCFPKL9S3S TREXLFPKL9S3S
    TREXCHPKL9P1S TREXLHPKL9P1S TREXCFPKL9P1S TREXLFPKL9P1S
    TREXCHPKL9P3S TREXLHPKL9P3S TREXCFPKL9P3S TREXLFPKLWS3S
    Spare parts codes :
    TREX-0002-1211 Rechargeable Li-Ion Power Module
    TREX-0002-3611 Rechargeable Li-Ion Power Module (with 3 years premium coverage)(2)
    TREX-0003-0011 AC Adapter (includes US, EU, UK, AU outlet plugs)
    TREX-0003-0022 DC Adapter (12v vehicle accessory outlet)
    TREX-0003-0002 AC Outlet Plugs (replacement set includes US, EU, UK, AU)
    TREX-FFPA-0001 Foundation Fieldbus Power Plug
    TREX-0004-0001 Lead Set with connectors
    TREX-0005-0002 Hand Strap (replacement set of 2)
    TREX-0005-0011 Carrying Case (includes hand & shoulder straps)
    TREX-0005-0009 Shoulder Strap (replacement for use with carrying case)
    TREX-0005-0004 Magnetic Hanger
    TREX-0004-0002 USB cable (USB to micro USB)
    TREX-PMDC-1211 Device Communicator communication module(3)
    TREX-PMDC-3611 Device Communicator communication module (with 3 years premium coverage)
    TREX-PMDP-1211 Device Communicator Plus communication module(3)
    REX-PMDP-3611 Device Communicator Plus communication module (with 3 years premium coverage)(2)(3)
    TREX-0012-0011 Stand (replacement integral to communication module)(
    TREX-0045-0001 Quick Start Guide (Multilingual)
    TREX-0049-0001 Resource DVD(5)
